888 Portable Production Mixer-Recorder

888

16 Channel - 20 Track Portable Production Mixer / Recorder

5,995.00 ex vat 7,194.00 inc vat

QTY

estimated delivery 2 - 3 Days

Sound Devices 888 Portable Production Mixer-Recorder

Meet the 888 - the portable mixer-recorder that’s compact and light enough to use in a bag, yet has the high channel count and power required for mobile cart productions. The 888 is the smallest portable mixer-recorder on the market that offers Dante for sending and receiving audio over Ethernet. With 8 ultra low-noise, 8-Series microphone preamplifiers, 16 channels, 20 tracks, multiple powering methods, and support for multiple USB control surfaces, the 888 can be easily tailored to your workflow. An updated processing architecture and multiple FPGAs enables the 888 to be fully routable: any physical input may be sent to any track, bus, or output.

Many features have carried over from the premium Sound Devices’ Scorpio, such as the new 8-Series preamplifier design, 2 SD card slots, internal 256GB SSD, and dual L-Mount battery charging and powering. Alternatively, power your 888 using a smart battery, NP-1 battery, or an in-line power supply via its TA4 DC input. The ultra-accurate, fully-featured timecode generator contains its own battery to hold timecode for up to four hours after power off.
Dedicated coms and slate allows for professional bi-directional communication with other crew members. Send customized mixes to the camera or crew with multiple mix buses. With
the ability to record to three media simultaneously, you can turn over an SD card to production, AAC files for transcription, and keep a backup on the internal 256 GB SSD.

A built-in three band EQ may be set to either pre- or post-fade for each channel to tackle any problems directly on-set. Enable Dugan Automixing or MixAssist to automatically attenuate unused microphones in multi-microphone applications.
Up to 16 channels can be automixed at a time.
Get the perfect fit on your cart with one of several supported USB control surfaces for remote fader and transport control. Download the companion Android app, SD-Remote, to access to transport controls, metering, and sound reports on a large touch screen.
Elevate your kit with the 888 Portable Production Mixer-Recorder.



Key Features

  • 8 Mic/Line Preamplifiers
  • 16 Channels, 10 Buses, 20 tracks
  • 16 Channels Dante I/O
  • Ultra-accurate timecode
  • 256 GB internal SSD, 2 SD card slots
  • USB-A and C ports for SD-Remote app, linear fader control via MCU, keyboard, and file transfer
  • Dugan Automixing for up to 8 channels





Frequency Response 10 Hz to 80 kHz ± 0.5 dB (192 kHz sample rate, re 1 kHz)
THD + Noise 0.005% max (1 kHz, 22 Hz–22 kHz BW, trim @20, fader @ 0, -10 dBu in)
Equivalent Input Noise -131 dBV (-129 dBu) max
(A-weighting, 76 dB gain, 150 ohm source impedance)
Processing Engine Highly extensible, full FPGA-based audio processing, 3 FPGAs
Six-way ARM multiprocessor system
64-bit audio processing precision
Inputs

Mic/Line inputs 8 total, all fully featured; 4 on full-size XLR, 3 on
TA3

Mic-level inputs: (XLR, TA3): Class-A, discrete differential long-tail
pair, 4k ohm input impedance
Line-level inputs: (XLR, TA3,): active-balanced, 4k ohm input
impedance
48V phantom: full 10mA to all 6 inputs simultaneously
AES3 or AES42 available on XLR input 1
AES42: +10 V, 250 mA available, mode-1, auto-ASRC
Aux (3.5 mm/10-pin): unbalanced 2-channel, 4k ohm input
impedance
Com Rtn (TA3, 3.5mm) balanced, 1-channel, 8k ohm input
impedance
External Slate Mic (TA5): balanced, 8k ohm input impedance,
menu-selectable 12 V phantom



Maximum Input Level

Mic: +8 dBu (2.0 Vrms)
Line: +28 dBu (19.5 Vrms)
Rtn A, B: +18 dBu (6.2 Vrms)
Com Rtn +24 dBu (12.3 Vrms)
External Slate Mic: +12 dBu (3.2 Vrms)

High-Pass Filters Adjustable 10 Hz to 320 Hz, 18 dB/oct. 1st stage analog (beforepreamp), 2nd stage digital.
Limiters Limiters available at all channels, buses, headphones, for all sample rates
Analog first stage, all subsequent stages digital
Attack time: 1 ms • Release time: adjustable, 50 ms to 1000 ms • Threshold: adjustable, -2 dBFS to -12 dBFS
Selectable ratio: inf:1, 20:1, 18:1, 16:1, 14:1, 12:1, 10:1
Delay Channel Adjustable 0-50 ms Output Adjustable 0-500 ms
Maximum Gain Trim stage (mic input): 76 dB
Trim stage (line input): 50 dB
Fader stage: 16 dB
Bus stage: 16 dB
Headphone stage: 20 dB
Mic-to-Line: 108 dB
Mic-to-Headphone: 112 dB
Outputs XLR (L, R) active-balanced, 250/3.2k/120 ohms (mic/-10/line)
TA3 (X1-X4) active-balanced, 250/3.2k/120 ohms (mic/-10/line)
3.5mm (X5-X8): unbalanced, stereo, 1.8k ohms
Headphone Outputs 1⁄4”, 3.5 mm
TA5 (along with mic input pins) for single connection to headset + mic
High output, 4 ohm output impedance, 400 mW + 400 mW at each connector, all individually driven
Compatible with headphones of any impedance
Maximum Output Level (all into 10k load) Line: +20 dBu (7.8 Vrms)
“-10”: +6 dBu (1.5 Vrms)
Mic: -20 dBu (0.078 Vrms)
X3/X4 Out: +6 dBu (1.5 Vrms)
Headphone outputs (1⁄4”, TA-5): +14 dBu (4.0 Vrms)
A/D converters 32-bit, 120 dB, A-weighted dynamic range typical
Sampling rates 44.1 kHz, 47.952 kHz, 48 kHz, 48.048 kHz, 88.2 kHz,96 kHz, 192 kHz
Digital Outputs AES3 transformer-balanced, in pairs; 1-2 (XLR-L), 3-4 (XLR-R), 110ohm, 2 V p-p, AES and S/PDIF compatible
Recording Internal 256 GB SSD • Two removable SD Cards
Simultaneous recording to internal SSD and the two SD cards
exFAT formatting
12 tracks (8 iso channels, 4 buses)
Broadcast WAV monophonic and polyphonic file format • 64-bit WAV (RF64) monophonic and polyphonic; support for files > 4 GB
Automixing Dugan Automixing up to 8 channels on left and right mix bus
USB USB-C (USB 3.1 type 1) for file transfer of internal SSD, both SD Cards
USB-A host for keyboard, external controller, external USB hubs
Timecode and Sync Modes Supported: Off, Rec Run, Free Run, 24h Run, External,including External Auto-Record and Continuous modes.
Frame Rates: 23.98, 24, 25, 29.97 DF, 29.97 ND, 30 DF, 30 ND
Sample/Timecode Accuracy: 0.1 ppm (0.25 frames per 24 hours)
Timecode Input: 20k ohm impedance, 0.3 V - 3.0 V p-p (–17 dBu - +3 dBu)
Timecode Output: 75 ohm impedance, 5 V p-p (+12 dBu)
Word Clock Input: 10k/75 ohm selectable impedance,1-5 V p-p input sensitivity
Word Clock Output: 75 ohm impedance, 5 V p-p output, at SR
Remote Control

USB MIDI Control - 3rd party fader controllers
SD-Remote Android app
CL-12 Support
USB Keyboard
External Timecode Record Trigger

LCD 320x240, Transflective, excellent sunlight visibility
Larger touchscreen display available via USB-connected SD-Remote app
Power

External dual: 10-18 V input on locking TA4 connectors, pin-4 = (+), pin-1 = (-)
Dual rear-mount Sony style with charging facility
Intelligent power-down of unused mic preamps and other internal circuits

Environmental Operating: -20° C to 60° C, 0 to 90% relative humidity (non-condensing)
Storage: -40° C to 85° C
Dimensions(H x W x D) 5.1 cm x 24.5 cm x 18.5 cm; (2.0 in. x 10.0 in. x 7.3. in)
Weight 4.0 lbs (1.83 kg) unpackaged, without batteries
