The 833 is the professional’s tool for mobile and small productions. Like the popular Sound Devices 633, the 833 is small, lightweight, and compact. A tactile interface with dedicated faders, trim knobs, and PFL switches makes this mixer-recorder ideal for run-and-gun bag use.
The 833 has 6 mic/line preamplifiers, 8 channels, 12 tracks, 6 analog outputs, and ultra-accurate timecode. Upgrade with the +4 Plugin to add four fully-featured ISO channels/record tracks, increasing the 833 to 12 channels & 16 tracks. Many features have carried over from the premium Sound Devices’ Scorpio, such as Sound Devices’ new preamplifier design, 2 SD card slots, dual L-Mount battery charging and powering, and an internal 256 GB SSD.
Additionally, the 833 shares the same processing architecture and multiple FPGAs as the Scorpio. This enables the 833 to be fully routable, and any physical input can be routed to any track. The 833 features both digital and analog inputs and outputs, and has multiple powering options, so it will fit effortlessly into your existing kit.
A built-in three band EQ may be set to either pre- or post-fade for each channel to tackle any problems directly on-set. Enable Dugan Automixing or MixAssist to automatically attenuate unused microphones in multi-microphone applications. Up to 8 channels can be automixed at a time. If you are recording in a noisy environment, enable the optional NoiseAssist or CEDAR sdnx plugins to suppress common background noises instantly on-location.
Dedicated coms and slate allows for professional bi-directional communication with other crew members. Send customized mixes to the camera or crew with multiple mix buses. With the ability to record to three media simultaneously, you can turn over SD cards to production at the end of the day while keeping a backup on the internal 256 GB SSD.
The 833 may be controlled via the companion Android and iPad app, SD-Remote, which features transport controls, metering, and sound reports. For an instant mobile workstation, choose from one of several supported USB control surfaces for remote fader and transport control. The SL-2 Dual SuperSlot Wireless Module easily mounts to the top panel, providing up to four channels of wireless audio in each slot.
Expand this to 16-channels of wireless audio with the A20-Nexus. Connection via the top panel with an A20-QuickDock provides totally cable-free solution for all power, audio and GainForward.
Elevate your kit with the 833 Portable Compact Mixer-Recorder.
The 833 ships with the XL-WPTA4, XL-ANT2.4, and includes 1 XL-LCD-PROTECT protective cover.
Register your 833 to upgrade your 1 year warranty to a 2 year warranty.
Key Features
Frequency Response | 10 Hz to 80 kHz ± 0.5 dB (192 kHz sample rate, re 1 kHz) |
---|---|
THD + Noise | 0.005% max (1 kHz, 22 Hz–22 kHz BW, trim @20, fader @ 0, -10 dBu in) |
Equivalent Input Noise | -131 dBV (-129 dBu) max (A-weighting, 76 dB gain, 150 ohm source impedance) |
Processing Engine | Highly extensible, full FPGA-based audio processing, 3 FPGAs Six-way ARM multiprocessor system 64-bit audio processing precision |
Inputs |
Mic/Line inputs 6 total, all fully featured; 3 on full-size XLR, 3 on pair, 4k ohm input impedance Line-level inputs: (XLR, TA3,): active-balanced, 4k ohm input impedance 48V phantom: full 10mA to all 6 inputs simultaneously AES3 or AES42 available on XLR input 1 AES42: +10 V, 250 mA available, mode-1, auto-ASRC Aux (3.5 mm/10-pin): unbalanced 2-channel, 4k ohm input impedance Com Rtn (TA3, 3.5mm) balanced, 1-channel, 8k ohm input impedance External Slate Mic (TA5): balanced, 8k ohm input impedance, menu-selectable 12 V phantom
|
Maximum Input Level | Mic: +8 dBu (2.0 Vrms) Line: +28 dBu (19.5 Vrms) Rtn A, B, C: +18 dBu (6.2 Vrms) Com Rtn 1, 2: +24 dBu (12.3 Vrms) • External Slate Mic: +12 dBu (3.2 Vrms) |
High-Pass Filters | Adjustable 10 Hz to 320 Hz, 18 dB/oct. 1st stage analog (beforepreamp), 2nd stage digital. |
Limiters | Limiters available at all channels, buses, headphones, for all sample rates Analog first stage, all subsequent stages digital Attack time: 1 ms • Release time: adjustable, 50 ms to 1000 ms • Threshold: adjustable, -2 dBFS to -12 dBFS Selectable ratio: inf:1, 20:1, 18:1, 16:1, 14:1, 12:1, 10:1 |
Delay | Channel Adjustable 0-50 ms Output Adjustable 0-500 ms |
Maximum Gain | Trim stage (mic input): 76 dB Trim stage (line input): 50 dB Fader stage: 16 dB Bus stage: 16 dB Headphone stage: 20 dB Mic-to-Line: 108 dB Mic-to-Headphone: 112 dB |
Outputs | XLR (L, R) active-balanced, 250/3.2k/120 ohms (mic/-10/line) TA3 (X1/X2) active-balanced, 250/3.2k/120 ohms (mic/-10/line) 3.5mm (X3/X4): unbalanced, stereo, 1.8k ohms |
Headphone Outputs | 1⁄4”, 3.5 mm TA5 (along with mic input pins) for single connection to headset + mic High output, 4 ohm output impedance, 400 mW + 400 mW at each connector, all individually driven Compatible with headphones of any impedance |
Maximum Output Level (all into 10k load) | Line: +20 dBu (7.8 Vrms) “-10”: +6 dBu (1.5 Vrms) Mic: -20 dBu (0.078 Vrms) X3/X4 Out: +6 dBu (1.5 Vrms) Headphone outputs (1⁄4”, TA-5): +14 dBu (4.0 Vrms) |
A/D converters | 32-bit, 120 dB, A-weighted dynamic range typical Sampling rates 44.1 kHz, 47.952 kHz, 48 kHz, 48.048 kHz, 88.2 kHz,96 kHz, 192 kHz |
Digital Outputs | AES3 transformer-balanced, in pairs; 1-2 (XLR-L), 3-4 (XLR-R), 110ohm, 2 V p-p, AES and S/PDIF compatible |
Recording | Internal 256 GB SSD • Two removable SD Cards Simultaneous recording to internal SSD and the two SD cards exFAT formatting 12 tracks (8 iso channels, 4 buses) Broadcast WAV monophonic and polyphonic file format • 64-bit WAV (RF64) monophonic and polyphonic; support for files > 4 GB |
Automixing | Dugan Automixing up to 8 channels on left and right mix bus |
USB | USB-C (USB 3.1 type 1) for file transfer of internal SSD, both SD Cards USB-A host for keyboard, external controller, external USB hubs |
Timecode and Sync | Modes Supported: Off, Rec Run, Free Run, 24h Run, External,including External Auto-Record and Continuous modes. Frame Rates: 23.98, 24, 25, 29.97 DF, 29.97 ND, 30 DF, 30 ND Sample/Timecode Accuracy: 0.1 ppm (0.25 frames per 24 hours) Timecode Input: 20k ohm impedance, 0.3 V - 3.0 V p-p (–17 dBu - +3 dBu) Timecode Output: 75 ohm impedance, 5 V p-p (+12 dBu) Word Clock Input: 10k/75 ohm selectable impedance,1-5 V p-p input sensitivity Word Clock Output: 75 ohm impedance, 5 V p-p output, at SR |
Remote Control | USB MIDI Control - 3rd party fader controllers • SD-Remote Android app USB Keyboard External Timecode Record Trigger |
LCD | 320x240, Transflective, excellent sunlight visibility Larger touchscreen display available via USB-connected SD-Remote app |
Power | External: 10-18 V input on locking TA4 connectors, pin-4 = (+), pin-1 = (-) |
Environmental | Operating: -20° C to 60° C, 0 to 90% relative humidity (non-condensing) Storage: -40° C to 85° C
|
Dimensions(H x W x D) | 5.1 cm x 22 cm x 17 cm; (2.0 in. x 8.7 in. x 6. in) |
Weight | 2.75 lbs (unpackaged, without batteries) 1.25 kg (unpackaged, without batteries) |
