Clean, Easy Ergonomics
The Deity DIFB features a modern interface with a large color screen that makes navigating the menu and settings easy.
The home screen features the current frequency and volume, controlling which one you are interacting with can easily be switched between by pushing down on the rotatory encoder.
Beyond Global OneBand™ Technology
The Deity DIFB has a tunable ultra-wideband range of 550 MHz to 960 MHz. And by using your phone's GPS, the IFB will conform to local RF rules in different countries.
20 Bank Library
Sometimes production people need to tune into more than just a single signal. The DIFB is able to store up to 20 different frequencies that you can rotate through via the rotatory knob.
Up to 17Hrs of Battery Life
The DIFB pushes the boundaries with 210% the battery life vs some of the legacy devices.
The DIFB also features a USB-C port that can act as an external power port.
Text to Speech Notifications
Because the DIFB often will be clipped to your belt or in a pocket, you won’t be able to see the screen. So how do you know which preset FREQ you’ve dialed into?
The DIFB will read out the DID name of the signal in your headphones.
Wireless Setup via Sidus Audio App
The app allows you to perform frequency scanning, bank library programing, bulk updating, and frequency coordination.
The remote control feature is especially useful for filmmakers who need to work with multiple devices or those who need to make adjustments to their audio settings quickly. IFB x Sidus saves time.
The Deity DBTX sets itself apart by using an ultra-broad UHF spectrum. This transmitter's frequencies range from 550-960 MHz. (The actual band size and spectrum will depend on where the device is used; SEE MORE FOR DETAILS).
The Theos ecosystem's most unique feature is that the transmitter can be natively synced wirelessly from the Deity TC-1 timecode generator. Timecode ensures your alternative WAV files will sync with your camera footage in post. Alternatively, the DBTX can be synced via the 3.5mm jack if you are using 3rd party timecode generators.
DIFB Specification and Parameters | |
---|---|
RF Modulation | Proprietary Digital RF Modulation |
RF Frequency Ranges | According to different regions, the legitimate frequency bands in line with local conditions are allocated |
RF Frequency Step | 100kHz |
RF Bandwidth | 200kHz |
Minimum Frequency Interval |
700kHz |
Antenna Connector |
2x 50Ohm SMA |
Dynamic Range | 105 dBm |
Distortion | <0.5% |
DAC Bit-Depth | 24 bit |
Battery Type | 2x AA Battery |
Battery Life (DEITY AA/Turn off BT) | 17h |
Dimentions (H x W x D) | 82.5 x 64.21 x 19.90 mm |
Weight |
Without battery and antenna: 105.5g Without battery with antenna: 116.5g With battery and antenna: 148.5g |
Operating Temperature | -20C~45C (-4F~133F) |
Suggested Impedance for headphones | <64 Ohms |
DBTX Specification and Parameters | |
---|---|
RF Modulation | Proprietry Digital RF Modulation |
RF Feq Ranges | According to different regions, the legitimate frequency bands in line with local conditions are allocated |
RF Frequency Step |
100kHz |
RF Bandwidth | 200kHz |
Minimum Frequency Interval | 700kHz |
Antenna Connector | 50 Ohm SMA |
Power Output | 10/ 20/ 25/ 50/ 100mW - Software Selectable (varies by regulation) |
Dynamic Range | 123dB |
Distortion | <0.5% |
Frequency Response | 20~20kHz |
Low Cut | OFF /75Hz /100Hz /150Hz |
Mic Power | Mic, Line |
Mic Connector | 3.5mm TRS |
Input Gain | 0~+30dBu |
ADC Bit-Depth | 2 x 24bit |
ADC Sampling Rate | 48kHz |
Clock Accuracy | 0.25 PPM (1 Frame Out in 48 Hours) |
Timecode Type | LTC (SMPTE) |
Timecode Frame-rates | 23.98, 24, 25, 29.97, 29.97DF, 30, 30DF |
Media | MicroSD Card (Flash Memory) |
File Format | .wav |
Sample Rate | 48kHz |
Record Format | 24/32bit float |
Battery Life | Up to 12+ Hours with 2x Deity AA |
